Engine Type
4 Stroke, 4 Valve, Single Cylinder Liquid Cooled, DOHC
Bore & Stroke
73.00 mm x 50.00 mm
Max Power
25.5 PS @ 9250 rpm
Max Torque
20.4 Nm @ 7250 rpm
Front Suspension
Dia 37 mm, Telescopic Front Forks with Anti Friction Bush
Rear Suspension
Gas Charged Mono Shock, 6 Step Pre-load Adjustable DOWNLOAD SPECS Share
Frame Type
Steel Trellis Frame
Transmission Type
Constant Mesh , 6 Speed
Swing Arm
Rectangular Swing Arm
Clutch Type
Wet type Slip & Assist
Front Brake Type
Dia 300 mm, Petal Disc
Front Brake Type
Dia 230 mm, Petal Disc
Front Tyre Size
100/80-17 TL
Rear Tyre Size
140/70-17 TL
Battery
MF Battery 12V- 6 Ah, ETZ-7
HeadLamp
Auto Illuminated Class-D LED Projector Headlamp,
Tail Light
Signature H Shaped LED Tail Light
Cooling System
Air Cooled
Overall Length
2068.00 mm
Overall Height
Signature H Shaped LED Tail Light mm
Ground Clearance
160.00 mm
