Engine Type
Air cooled, 4-stroke Single Cylinder OHC
Bore & Stroke
50.00 mm x 56.50 mm
Max Power
6.0kW PS @ 7000 rpm
Max Torque
8.70 Nm @ 5500 rpm
Front Suspension
Bottom link with spring-loaded hydraulic dampers
Rear Suspension
Swing Arm with spring-loaded hydraulic dampers
Frame Type
high rigidity under bone type.
Transmission Type
Dry, Automatic
Clutch Type
dry, automatic centrifugal clutch system
Front Brake Type
Internal Expanding Shoe Type (130 mm)
Front Brake Type
Internal Expanding Shoe Type (130 mm)
Front Tyre Size
90/100 x 10-53 J (Tubless)
Rear Tyre Size
90/100 x 10-53 J (Tubless)
Battery
12V-4Ah ETZ-5 MF-Battery
HeadLamp
12-v LED, projector Technology
Tail Light
12V-5W/21W Multi-Focal Reflector Type
Cooling System
Air Cooled
Overall Length
1769.00 mm
Overall Height
12V-5W/21W Multi-Focal Reflector Type mm
Ground Clearance
155.00 mm
